A2V Series Rules

General

Class 1 - Flat Bottom Atlantic - Formula Atlantic’s with no tunnels. Ostensibly, this means up to 1979. But if you show up with a March 80A with 79B sidepods, that’s fine by us. Iron block 1600 BD’s on carbs.

Class 2 - Tunneled Atlantic - Formula Atlantic up to ‘86. Again, this is a fuzzy cutoff. What we don’t want (for now) is Toyota’s or carbon tubs. So if you have an ‘87 or ‘88 Ralt RT4, you’re welcome to race with us. But for now guys, sorry no DB4’s or Toyotas. Iron block 1600 BD’s on carbs.

Class 3 - SuperVee - This one covers a lot of ground, as the SuperVee landscape is as varied as the American West. 1600cc, 1800cc, who-knows-what cc, carbs, mechanical injection, electronic injection, VW brakes, Atlantic brakes, 6”/8” wheels, 8”/10” wheels, Atlantic wheels… Trying to keep all this in line will be a dizzying proposition. We are going to keep this simple: if your car has a watercooled VW engine - it’s a SuperVee in our series. Going forward, SuperVee folks are going to vote with your wallets. If we have 12 SV’s show up at every round, and 10 of them have 1800cc electronic injected engines, guess what the rules will look like for year two? Show up and show out. Your participation will help guide the series going forward. 1989 is the cutoff, but since the SV series allowed partial composite tubs in period way before 1989, (see Anson), we will allow them.

Class 4 - Formula 2 - There are very few pukka F2 cars in the US, but we wanted to have a class for them. We are allowing up to 1984 (as F3000 replaced F2 in 1985), but the other reason we wanted a space for this class is it allows us a place to put “less than compliant” FA’s. Injection, alloy blocks, Hart 420R’s, BMW M-12’s, Cosworth BDG’s etc.

Caveats and Notes -

  1. This will be a gentleman’s series. That means we all need to act as such. We will treat our drivers and entrants as gentlemen, and expect that they conduct themselves as such. For this series to thrive, we need camaraderie and fellowship. We want the race on Saturday to be of equal importance to the post-race beer and awards presentation.

  2. Cars will be prepared to period. If you can prove your BT40 ran a March 76B wing in period (this means photographic proof), we will allow it. But what we don’t want is modded up cars with relocated pickup points, modern shocks, stressed oil pans (in cars where they were not), etc. Again, when all else fails, see #1 above.

  3. WE WILL FOLLOW ALONG WITH ANY VMC SUSPENSIONS. If you are sat down by your local VMC club for a 13/13, don’t bother entering an A2V race. Similarly, we will take on track infractions seriously and if need be, take appropriate action.

  4. If you show up with an fuel injection on your Atlantic, you automatically get moved to F2. If you show up with a 1700cc engine in your Atlantic, you automatically get moved to F2. If you show up with an alloy block in your Atlantic… well, you get the drill. We don’t want to send anyone home here, we want everyone to come race with us. BUT, we want folks to know they are on a level playing field. Along those lines, we reserve the right to place someone in a different class based upon the build of their car.

  5. Tires - for Season 1 we will have an open tire rule. All cars must run 13” diameter tires. Competitors must qualify and race on same tires which will be marked by series officials. (one tire changed with proof of damage without grid position penalty. Two or more tires changed, you forfeit your grid spot and will start at the back). Season 2 and later we will require all competitors to run on Avon/Nova.

  6. Post Race we will have parc ferme for the entire grid. This will allow us to police any rules infractions on site, as well as check for compliance and air any driving grievances immediately.

CLASS RULES

1971-1979 Formula Atlantic Supplemental Regulations

· Approved engines (basically saloon car steel block):

· Alfa T/C, BMW 1.6 SOHC, Fiat 124 DOHC, Datsun 1600 SOHC, Cosworth BDA & BDD, Lotus T/C, Ford 1500 & 1600 pushrod, Porsche 1582cc, Renault 1600cc

· Maximum bore is .030” over stock, Maximum stroke is stock size

· Oversize engines will be addressed on a case by case basis.

· Fuel Injection not allowed

· Minimum weight 1050 lbs. Weights are measured post race WITH driver. All competitors should arrive at the track with ballast and a safe way to mount it to the car.

· Max 5 forward gears

· No ground effect side skirts allowed

· No ground effect tunnels

· Wings original positions, same type (element number) period profiles

· Front wing leading edge airfoil radius =.6" (1.5cm).

· Bodywork or aerodynamic devices (wings) in front of the front tires shall not exceed 59.055" (150cm).

· Rear wing width = 110cm - 43.307" · Rear wing set-back = 39.4" from CL of rear wheel to end of rear wing

· Rear wing height = 34.5" measured on a horizontal plane from the ground w/o driver

· No Carbon/Kevlar composite body panels

· Shocks: · Non-pressurized shocks maybe double adjustable (e.g. 8212 KONI), Pressurized shocks shall be non-adjustable and no remote reservoir allowed (e.g. Bilstein)

· Wheels shall be 13” diameter

· Tires: applicable sizes and compounds from Avon, Hoosier and Goodyear allowed

· Clutch pack to be no smaller than 7.25 inches. Driven plates must be sintered metal. They can be nested or stacked.

1980-1986 Formula Atlantic Supplemental Regulations

· Tubs shall be comprised entirely of aluminum and steel, no composite tubs allowed (specifically, this rule is to allow RT4's but not DB4's)

· Approved engines (basically saloon car steel block):

· Cosworth BDA & BDD · Oversize engines will be addressed on a case by case basis.

· Maximum bore is .030” over stock, Maximum stroke is stock size

· Fuel Injection not allowed

· Minimum weight 1175 lbs measured with driver. All competitors should arrive at the track with ballast and a safe way to mount it to the car.

· Max 5 forward gears

· Ground effect side skirts allowed so long as no part of the skirt extends below any part of the tub (the tub shall be the lowest point of the car)

· Wings original positions, same type (element number) period profiles

· Front wings Front wing leading edge airfoil radius =.6" (1.5cm). Bodywork or aerodynamic devices (wings) in front of the front tires shall not exceed 59.055" (150cm).

· Rear wings Rear wing width = 110cm - 43.307" Rear wing set-back = 39.4" from CL of rear wheel to end of rear wing Rear wing height = 34.5" measured on a horizontal plane from the ground w/o driver

· Shocks: · Shocks are open so long as they are of period design and manufacture (e.g. Koni, Fox, Bilstein, etc. Shocks of modern manufacture such as Penske, Ohlins, Dynamic, Moton shall not be allowed)

· Wheels shall be 13” diameter

· Tires: applicable sizes and compounds from Avon, Hoosier and Goodyear allowed

· Clutch pack to be no smaller than 7.25 inches. Driven plates must be sintered metal. They can be nested or stacked.

1971-1984 Formula 2 Supplemental Regulations

· Tubs shall be comprised entirely of aluminum and steel, no composite tubs allowed

· Approved engines:

· Cosworth BDD, BDE, BDF, BDG, Cosworth FVA/FVC, BMW M12/7, Hart 420S and 420R

· Maximum bore is .030” over stock, Maximum stroke is stock size

· Oversize engines will be addressed on a case by case basis.

· Mechanical fuel injection allowed, electronic injection is not

· Minimum weight 1200 lbs (measured with driver). All competitors should arrive at the track with ballast and a safe way to mount it to the car.

· Max 5 forward gears

· Ground effect side skirts allowed so long as no part of the skirt extends below any part of the tub (the tub shall be the lowest point of the car)

· Wings original positions, same type (element number) period profiles

· Front wings Front wing leading edge airfoil radius =.6" (1.5cm). Bodywork or aerodynamic devices (wings) in front of the front tires shall not exceed 59.055" (150cm).

· Rear wings Rear wing width = 110cm - 43.307" Rear wing set-back = 39.4" from CL of rear wheel to end of rear wing Rear wing height = 34.5" measured on a horizontal plane from the ground w/o driver

· Shocks: · Shocks are open so long as they are of period design and manufacture (e.g. Koni, Fox, Bilstein, etc. Shocks of modern manufacture such as Penske, Ohlins, Dynamic, Moton shall not be allowed)

· Wheels shall be 13” diameter

· Tires: applicable sizes and compounds from Avon, Hoosier and Goodyear allowed

· Clutch pack to be no smaller than 7.25 inches. Driven plates must be sintered metal. They can be nested or stacked.

1978-1989 Super-Vee (Water Cooled) Supplemental Regulations

(Based on SCCA Rules)

I. Car Construction

A single-seat open wheel racing car based on original VW engine components.

A. The only original VW standard components which will be accepted are those appearing in the manufacturing

company’s parts. They must have been subjected to all the manufacturing processes which the company applies to parts for incorporating into standard production vehicles.

B. Other equipment and components are only allowed if expressly authorized by these regulations.

C. All VW components may be reworked according to the details of these regulations only. Any modifications not expressly listed herein are prohibited.

D. It must always be possible to positively identify any reworked parts as VW standard parts. Provided that the origin of a standard part can definitely be established, it may be aligned, balanced, fitted, reduced in size or otherwise reshaped or modified by reworking.

E. Unless authorized by these regulations, no new material may be added in any way to VW parts. Specifically, no material may be added to the engine by welding, adhesive joints, electrolysis, etc. Chassis and body parts, however, may be plated or painted to enhance their appearance.

F. Except for the crankshaft, engine parts may not be nitrided or treated in salt baths.

G. Bolts, nuts, spring washers and other types of washers are free.

II. Weight and Dimensions

A. Minimum weight - 1050 for flat bottom, 1175 for tunneled, both weights with driver. All competitors should arrive at track with ballast and a safe way to mount it in the car

B. Wheel base – free

C. Front track – free

D. Rear track – free

III. Suspension

A. Front wheel suspension is free.

B. The steering mechanism may be of free design.

C. Any form or rear wheel suspension may be used, provided it incorporates standard VW constant velocity joints.

D. Shock absorbers shall be maximum two-way adjustable

IV. Wheels

A. Any make of wheel rim may be used. The following dimensions are compulsory:

1. Diameter: 13"

2. Maximum rim width: open - A2V Series note: year 1 will determine rules going forward in this line item

V. Brakes

A. Brake lining and/or brake pad material is free.

B. Cars must be equipped with a dual braking system operated by a single control. In case of a leak or failure at any point in the system, effective braking power shall be maintained on at least two wheels. Brake master cylinders

are free.

C. The following standard VW parts must be used [reworking to fit is permitted].

1. Brake disc.

2. Brake caliper.

VI. Water-Cooled Engine

An engine with a maximum displacement of 1600 cc must be used. It must be made of standard VW components from the engine production series intended for the Rabbit [Golf], Scirocco or Dasher [Passat].

Valves, valve guides and valve seats are free provided the number of valves per cylinder and distances between valves is not changed. Valve springs, valve spring caps and valve spring washers are free. VW cylinder head bolts must be used. Bolt-on valve covers are mandatory. Emission control air injection holes in the cylinder head [standard VW U.S. mode] may be plugged with standard pipe plugs provided they serve no other purpose than to blank off these external holes.

A. Induction System

1. Not more than two 2-barrel or four single-barrel carburetors shall be used.

2. Fuel injection is also permitted, but no form of supercharging shall be used.

3. Engine speed control must be by means of throttle butterflies.

4. The intake pipe to each cylinder must incorporate an air venturi and a max. diameter of 32 mm for fuel injection and 36 mm for carburetors directly ahead of the throttle butterfly, and all intake air for each cylinder must pass through it [or the entire fuel-air mixture if prepared before this point]. The fuel injection system and carburetors must employ individual runner intake manifolds [4] with no plenum or balance pipe.

5. Carburetor choke [cold start] passages are to be sealed with plugs.

6. Any type of ignition system [except twin spark plugs] may be used.

B. Other Engine Components

1. Engine mountings are free. The fan and water pumps can be modified, replaced or discarded. The coolant circuit is free. In its installed position, the engine may not be tilted more than fifteen [15] degrees to the right or left from the vertical. The engine must be installed along the vehicle’s longitudinal axis.

2. A single dry plate clutch is compulsory. A VW flywheel must be used.

C. Exhaust System

1. The exhaust pipes from all cylinders must lead rearwards. Their actual design or construction is free, provided the tail [outlet] pipes are not higher than 24 inches from the ground. The ends of the pipes must not project by more than 26 inches rearward of the rear axle centerline.

K. Bushings may be installed where none are fitted as standard, provided they are concentric and the centerline of the bushed part is not changed. No component shall be relocated and no prohibited modifications shall result from the use of the above bushing.

VII. Transmission

A. A VW gearbox housing incorporating not more than five [5] forward speeds and an operational reverse gear must be used. Reworking to adapt to the VW engine and to accept various gear ratios is permitted. Side plates may be modified or replaced.

B. Limited slip, locking differentials, or fully-locked differentials, are allowed but frowned upon.

VIII. Bodywork Shape and Material:

A. Vehicle bodywork shape and material are unrestricted. The body may consist of several panels. However, the bodywork must not extend beyond the rear-most point on the rear wing or spoiler. No part of the body or frame may be wider overall than 55.1 inches [1400 mm].

B. The maximum body height is 35.4 inches [900 mm] above the ground under all conditions with driver on board.

C. The bodywork ahead of the front wheels must not exceed 39.4 inches [1000 mm] measured from the centre of the front wheel hub. The maximum width of body sections ahead of the front is 53.1 inches [1350 mm]. No part of the body ahead of the front wheels and exceeding the overall width of 37.4 inches [950 mm] may extend upwards beyond the upper edge of a front wheel rim.

D. The cockpit opening must have the following minimum dimensions:

Length: 26.6 inches [600 mm]

Width: 17.7 inches [450 mm]

This width must extend over a length of 11.8 inches [300 mm] measured forward from the rearmost point on the

seat back. The driver must be able to enter or leave the car at any time without any parts having to be removed or manipulated.

E. Rear wings [aerodynamic aids] are permitted subject to the following conditions:

1. They must be adequately secured to the fully sprung mass of the vehicle and be firmly fixed when the car is in motion. They must be mounted symmetrically to the vehicle’s longitudinal axis.

2. The maximum height of the wing or spoiler from the ground under all conditions [including driver on board] must not exceed 35.4 inches [900 mm].

3. The maximum width of the wing must not exceed 37.4 inches [950 mm].

4. The horizontal distance between the rear edge of the wing and the centre of the rear wheel hub [rear axle centerline] must not exceed 31.5 inches [800mm].

F. Front wings or spoilers are permitted under the following circumstances:

1. They must be mounted firmly to the full sprung part of the vehicle and be adequately secured. They must be mounted symmetrically to the car’s longitudinal axis.

2. They must not interfere with the driver’s view when he/she is seated in the cockpit.

3. They must comply with the dimensional restrictions noted above.
